32PIN COG LCD Display with ST7567 Controller and 3.3V Operating Voltage for Industrial Applications

32PIN COG LCD Display 3.3V VTN NEGATIVE 1/32DUTY 1/6BIAS 9.5V ST7567

Product Description

ABSOLUTE MAXIMUM RATINGS:

32PIN COG LCD Display 3.3V VTN with 1/32DUTY and 1/6BIAS 9.5V ST7567 is a liquid crystal display module with specific technical specifications. The following is an introduction to it:

Product Introduction:

Type and Packaging: This is a liquid crystal display module using chip-on-glass (COG) packaging technology. COG packaging directly bonds the chip to the glass, which can reduce the module size and improve reliability.
Power Supply Voltage: The operating voltage is 3.3V, which is a low-voltage supply, suitable for circuit systems with low power consumption requirements.
Display Characteristics: It adopts VTN (Vertical Orientation Negative) liquid crystal technology, with a 1/32DUTY (duty cycle) and 1/6BIAS (bias) driving method. This driving method enables the liquid crystal display to maintain good display effect and stability when driving multiple pixels. Its display contrast and other parameters are supported by a 9.5V driving voltage.
Resolution and Size: The resolution of this type of module is usually 128×32 or 132×32, and the common size is approximately 34.5mm×15mm×1.7mm, with a window size of about 31.9mm×9.5mm.
Driver Chip: It uses the ST7567 driver chip. This chip is a controller chip for graphic liquid crystal displays launched by STMicroelectronics, integrating LCD driver and controller functions, supporting 8-bit parallel interface and SPI serial interface, and having built-in 1KB display RAM.

Product Applications:

Portable Devices: Due to its low power consumption and small size, it is often used in handheld instruments, smart wearable devices, such as handheld multimeters, thermometers, smart bracelets, etc., to display measurement data, status information, etc.
Industrial Control Systems: It can be used in industrial instruments to display operating parameters and status indicators, and can work stably in industrial environments, providing clear display effects.
Consumer Electronics: Such as electronic tags, home appliance control panels, etc., to display product information, home appliance working status, etc.
Medical Equipment: It can be used to display vital sign data, such as heart rate, blood oxygen saturation, etc., providing clear visual feedback for medical staff and patients.
